Wire Sheet Rolling Machine

Wire Sheet Rolling Machine
Wire Sheet Rolling Machine
Product Code : 09
Brand Name : AMOL
Product Description

Catering to diverse requirements of clients, we are renowned for manufacturing and exporting the best range of Wire Sheet Rolling Machine. These machines are extensively used in engineering and construction industry. Capable of rolling all types of metal sheets, these machines are available for clients in a wide range of specifications and models for meeting their individual requirements. This Wire Sheet Rolling Machine is stringently tested on various standard quality parameters prior to final dispatch in market.

Features:

  • Robust built
  • Can sustain adverse conditions
  • Consume less power

Technical Specification :

Dimension in mm / Model

ADM 001

ADM- 002

ADM 003

Rolls Width x Diameter

101 x 57

127 x 63.5

152 x 76

Wire Grooves From to

0.75 -- 8

0.75 -- 9

0.75 -- 10

Max Sheet Width can be Rolled

60

80

100

Max Apertures of Rolls

25

31

38

No of Half Round Grooves

2

2

2

Max. Roller Speed

7.57 (M/min)

9.42 (m/min)

11.66 (m/min)

Depth Per Rotation of Staring

0.78

0.5

0.66

Emergency Brake

Optional

Optional

Optional

Auto Lubricating System

Optional

Optional

Optional

Power Supply

1 HP / 0.75KW

1 HP / 1.1KW

2 HP / 1.5KW

1 Phase

1 Phase

1 Phase

Machine Dimension in cm

85 x 34 x 117

97 x 42 x 125

107 x 51 x 132

Machine Net Weight

220 KG

295 KG

355 KG

Shipping Dimension in cm

100 x 54 x 132

110 x 70 x 135

120 x 74 x 135

Shipping Weight

300 KG

360 KG

475 KG
